Battery Test Equipment-NEWARE

High-Speed communication & multi-channel acquisition

Supports CAN FD 2Mbps high-speed transmission and RS485 long-distance communication, with 8 fully isolated channels for simultaneous battery module data acquisition. Precisely monitors critical parameters including voltage, temperature, and current, meeting the demands of high-frequency, high-precision monitoring in new energy vehicles, energy storage systems, and similar applications.

Intelligent protocol compatibility

Built-in CANFDNET-200U protocol stack, compatible with mainstream software such as ZLG CANPRO. Features multi-TCP Server connections (up to 4 paths), customizable port configurations, IP binding, and seamless integration with BMS, thermal chamber monitoring systems, and other devices.

Ultra-low latency & lossless data capture

Achieves 8,000 frames/s CANFD transmit/receive capability per channel (total), combined with 16KB network cache + 200 CANFD message buffer. Ensures <20ms transmission latency for complete data integrity under extreme conditions, ideal for high-frequency pulse signals or burst data scenarios.

Robust industrial design

1.5kV electromagnetic isolation for network ports and signal paths. Operates reliably in -20°C to 50°C environments. Simplifies deployment with static IP configuration and web-based management interface, ensuring long-term stability in industrial settings with strong interference resistance.

Future-proof flexibility

Supports dual-mode switching (CANFD/CAN), configurable RS485 baud rates (9.6K–115.2Kbps), and independent arbitration field/data field speed adjustments (up to 5M/2M). Includes software/hardware upgrade interfaces to adapt to future battery technology advancements.
