Simple to operate, evenly applies pressure, used for formation testing of various sizes of pouch batteries.
Features
Tech Specs
Used to secure batteries, with a simple structure and easy operation, it ensures even pressure between the electrodes and contact pieces, improving the battery's conductivity and structural stability, preventing short circuits, and aiding in heat dissipation and extending the battery's service life.
| Equipment name | Flat Plate Fixture |
|---|---|
| Model | PCJ-YPB-R-D-95-120 |
| Battery Size | Length: 5.1" (130mm) Width: 3.5" (90mm) Thickness: 0.4" (10mm) |
| External Size | 5.9"×6.3"×1.7" (150×160×43mm) |
| Weight | 6kg |
