For prismatic cell testing. With a 500A test current capacity, designed for performance testing of blade batteries and VDA batteries.
Features
Tech Specs
With a 500A test current capacity, designed for performance testing of blade batteries and VDA batteries.
· Elbow joint clamps are utilized for easy and convenient battery placement and removal operations.
· Greatly enhances work efficiency, making the workflow smoother and more efficient.
· Adjustable elbow joint clamps accommodate different battery sizes by changing the tab spacing.
· Achieves flexible compatibility, offering a broader range of applications.
| Equipment name | 500A Prismatic Cell Toggle Clamp |
|---|---|
| Model | PCJ-F2-ZJ-500A-CH-L-1M |
| Current | 500A |
| Wire Terminal | M6/M16 |
| Battery Size | Length: 33.5"-43.3" (850-1100mm) Width: 3.5"-7.1" (90-180mm) Height: 0.6" (16mm) |
| External Size | 70.6"×10.2"×4.3" (1794mm×260mm×109mm) |
| Weight | 8kg |
