Used for power cylindrical battery cell performance testing, formation, and capacity grading.
Features
Tech Specs
Assembled with elbow clamps to ensure the battery conforms to the probe, combined with the A703-LK-TD300A-Z-02 positive probe, it is used for testing 300A cylindrical batteries, detecting parameters such as voltage and current, and performing battery performance testing, formation, and capacity grading.
| Equipment name | 300A Negative Probe |
|---|---|
| Model | A703-LK-TD300A-F-02 |
| Current | 300A |
| Probe Head Diameter | 0.63"(16mm) |
| Terminal | M16 |
