NEWARE aims at providing tailored solutions for batteries in various end-terminal scenarios such as bicycle-sharing and smart street lights, promoting low-carbon initiatives and creating a better city.
NEWARE not only produces excellent battery testing equipments, but also provides complete software and hardware solutions such as NEWARE AI, MES and automatic production line projects for battery industry enterprises and universities.
NEWARE has created exclusive customized solutions for multiple scenarios, serving more than 48,000 customers, with more than 327,000 devices in operation at the customer site.
NEWARE provides a rich selection of auxiliary modules and accessories to meet the complex needs of customers.
Voltage & Current Accuracy
Sampling Time
Current Response Time
Recording Frequency
Voltage & Current Accuracy
Voltage & Current Stability
Current Response Time
Off-line Test
Voltage & Current Accuracy
Voltage & Current Stability
Current Response Time
Recording Frequency
Compact in size, big on functionality
3U* height, high-efficiency cooling system, providing high-precision test reports.
Multi-range technology
8-channel design, each equipped with an independent constant voltage source and constant current source, which enhances the hardware's response time across a range of current levels.
Integrated operation
BTS host computer system realizes the integrated operation of battery test equipments and environmental test chambers to maximize the battery characteristics.
| Voltage & Current | Range 1 | Range 2 | Range 3 | Range 4 |
| 5V6A | 0.2mA ~ 100mA | 100mA ~ 500mA | 500mA ~ 3A | 3A ~ 6A |
| 5V12A | 0.2mA ~ 0.1A | 0.1A ~ 0.5A | 0.5A ~ 6A | 6A ~ 12A |
SMBus communication
It can communicate with the control circuit in the smart battery through SMBus communication protocol, and obtain the battery data in the smart battery, including production manufacturing information and real-time sampling data.
Multi-range technology
8-channel design, each channel independently programmed and controlled, with independent constant voltage source and constant current source.
Integrated operation
BTS host computer system realizes the integrated operation of battery test equipments and environmental test chambers to maximize the battery characteristics.
| Voltage | Current | |||
| 20V/24V/30V | 10A | 15A | 20A | 30A |
In high speed pulse, the ability to capture the current value at the moment of current switching is an important basis for special test application.
Multi-range technology
8-channel design, each equipped with an independent constant voltage source and constant current source, which enhances the hardware's response time across a range of current levels.
Integrated operation
BTS host computer system realizes the integrated operation of battery test equipments and environmental test chambers to maximize the battery characteristics.
| Voltage & Current | Range 1 | Range 2 | Range 3 | Range 4 |
| 5V6A | 0.1μA ~ 180μA | 180μA ~ 6mA | 6mA ~ 180mA | 180mA ~ 6A |
| 5V12A | 0.1μA ~ 300μA | 300μA ~ 10mA | 10mA ~ 300mA | 300mA ~ 12A |
