How to add multiple data files for comparison

Latest updated: Dec 14, 2023
Video recording version: 8.0.0.502, compatible with BTSDA 8.0 software.

Today, we will demonstrate how to add multiple data files for comparison.


  • First, open a BTSDA data file.

  • Next, click on the "Curve comparison" option in the top toolbar.

  • Then, by clicking the "+" in the upper left corner, you can select the comparison data to add your comparison curves.


That wraps up the entire demonstration. Thanks for watching.

This operation video tutorial is applicable to the following products:
● CT-4000 Battery Testing System Series (CT-4008Q-5V100mA, CT-4008Q-5V6A-S1, CT-4008Q-5V6A-164, CT-4008Q-5V12A-S1, CT-4008Q-5V12A-164, etc.)
● CE-6000 Battery Testing System Series (Cell, Module, Pack, etc.)
● CT/CTE-8000 Battery Testing System Series (CT-8002Q-5V100mA, CTE-8008-5V200A, etc.)
● All-in-One Battery Testing System Series (WHW-25L-S-16CH, WIHW-200-160CH-B, WHW-100L-2-160CH, WHW-500L-5V6A80CH-380V, WGDW-380L-2-40BFC-5V600A8CH, etc.)
