Setting for Direct Current Internal Resistance (DCIR) data report
Latest updated: Dec 15, 2023 Video recording version: 8.0.0.477, compatible with BTSDA 8.0 software.
Today, we will demonstrate how to set up a report for pulsed DCIR data.
First, open a BTSDA data and click on the "DCIR" option in the toolbar at the top.
Then, locate the "Report settings" to make modifications. Click "OK" to complete the setup.
That wraps up the entire demonstration. Thanks for watching!
This operation video tutorial is applicable to the following products: ● CT-4000 Battery Testing System Series (CT-4008Q-5V100mA, CT-4008Q-5V6A-S1, CT-4008Q-5V6A-164, CT-4008Q-5V12A-S1, CT-4008Q-5V12A-164, etc.) ● CE-6000 Battery Testing System Series (Cell, Module, Pack, etc.) ● CT/CTE-8000 Battery Testing System Series (CT-8002Q-5V100mA, CTE-8008-5V200A, etc.) ● All-in-One Battery Testing System Series (WHW-25L-S-16CH, WIHW-200-160CH-B, WHW-100L-2-160CH, WHW-500L-5V6A80CH-380V, WGDW-380L-2-40BFC-5V600A8CH, etc.)
